System

Main processor

NT98331

Interface

Preview

1/4/8/9

Video

Codec

H.265+

Monitor quality

VGA(1080P at most);HDMI(2K at most);CVBS

Preview ability

8*1080N (6 in 1)/4*5M-N (6 in 1)

Encode ability

8*1080N@15 fps(6 in 1)/4*5M-N@20fps(6 in 1)

Decode ability

8*1080N@15 fps(6 in 1)/4*5M-N@20fps(6 in 1)

Multi-mode

input

Analog：8*1080N；4*5M-N

hybrid：8*1080N（analog）+2*1080P（network）

 Network：16*1080P；8*5M

Motion Detection

Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel)

Audio

Coaxial audio

support

Audio compression

G.711A

Intercom

support

Record & playback

Record mode

manual>alarm>motion detection>timing

Local Playback

4ch(analog input mode)

Search mode

Search by time, calendar, event, channel

Storage & backup

Video storage

HDD, network

Backup mode

Network, USB hard disk, USB burner, SATA burner

External Interface

Video input

8ch BNC

Video output

1ch VGA, 1ch HDMI

Loop Vout

N/A

Audio I/O

4/1

Alarm I/O

0/0

Network interface

RJ45 10M/100M self-adaption

PTZ control

Support kinds of PTZ protocols

USB

2* USB 2.0 ports

HDD

1*SATA ports (Max 14TB)

Wireless

3G, WIFI (extend via USB)

General

Power supply

12V/2A

Power Consumption

<15W (without HDD)

Working environment

Temperature:0℃—+55℃，Humidity:10%—90%，Atm:86kpa—106kpa

Dimension

201mm*70mm

Weight

124g
