HS-NH-3004AE+AHD315C*4-AHD KIT-Products- Antai

	Model	AHB88N04R-LM
System	Main processor	NT98321
Interface	Preview	1/4/8/9
Video	Codec	H.265
	Monitor quality	hybrid mode VGA/ HDMI:1280*1024 at most; network mode VGA/ HDMI: 1080P at most
	Preview ability	4*1080N（6 in 1）
	Encode ability	4*1080N（6 in 1）
	Decode ability	4*1080N（6 in 1）
	Multi-mode input	Analog：41080N network：81080P;4*3M
	Digital to analog conversion	Unsupport（except hybrid mode）
	Motion Detection	Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel)
Audio	Audio compression	G.711A
	Intercom	support
Record & playback	Record mode	manual>alarm>motion detection>timing
	Local Playback	1ch(analog input mode)
	Search mode	Search by time, calendar, event, channel
Storage & backup	Video storage	HDD, network
	Backup mode	Network, USB hard disk, USB burner, SATA burner
External Interface	Video input	4ch BNC
	Video output	1ch VGA, 1ch HDMI
	Loop Vout	N/A
	Audio I/O	4/1
	Alarm I/O	0/0
	Network interface	RJ45 10M/100M self-adaption
	PTZ control	Support kinds of PTZ protocols
	USB	2* USB 2.0 ports
	HDD	1*SATA ports (Max 14TB/per)
	Wireless	N/A
General	Power supply	12V/2A
	Power Consumption	<15W (without HDD)
	Working environment	Temperature:0℃—+55℃，Humidity:10%—90%，Atm:86kpa—106kpa
	Dimension	135mm*82mm
	Weight	105g
