| Basic parameters | 2 million pixel 1080P series | |||
| Resolution | 1920*1080P | |||
| Frame rate | 1-25fps | |||
| Video format | PAL | |||
| Minimum illumination | Day mode 1.5LUX, night vision mode 0.1LUX (F2.0, AGC ON), | |||
| Signal to noise ratio | ≥38dB | |||
| CMOS performance | Support automatic white balance, automatic gain control, automatic backlight compensation | |||
| Lens/viewing angle | 3.6mm 2MP@F1.4 | |||
| Audio | Coding standard | Built-in omnidirectional noise canceling microphone and speaker for bidirectional real-time audio transmission ADPCM audio compression standard, adaptive stream | ||
| Audio input | 1 way built-in -38dB microphone | |||
| Audio output | Built-in 1 speaker 8 Euro 0.8W | |||
| Yuntai | control | 255 degrees horizontally, 60 degrees up and down | ||
| Preset setting | Support to set 1 preset position, one-click call | |||
| Video management | Video mode | Manual recording, alarm recording | ||
| Video storage | Cloud storage service; support for Micro SD card (maximum 128G) | |||
| wireless | WIFI802.11b/g/n wireless network, Wi-Fi wireless transmission (supports IEEE802.11b/g/n wireless | |||
| Call the police | Alarm input | / | ||
| Alarm detection | Support one button cloth / disarm | |||
| Motion Detection | stand by | |||
| Alarm screenshot | Support alarm screenshot push | |||
| System Requirements | System Configuration | Ios7.0, Android3.0 version or higher | ||
| Platform monitoring | Support, Android, Apple, tablet, PC, client real-time viewing monitoring | |||
| other | Power consumption | DC12V 2A / 7W | ||
| Operating temperature | Below minus 10-50 ° C | |||
| Working humidity | ≤95%RH | |||
| Installation method | Standard PTZ bracket Wall mounted | |||
